Olivijn
Multipurpose Dry Cargo Carrier | Vessel |
Length o.a.: 89,43 | Beam: 13,20
- Hold capacity (cbft)
- 195.569
- DWCC (t)
- 3.730
Key features
Number of vessels
5
Flag
Dutch
Trading Area
European continent
Open hatch, fully box
Ice class
Polar code
Tween decks
Bulk heads
Yes
Dehumidifying system
High intake
Lifting capacity
Main particulars
Shipyard
Instalho Scheepsbouw B.V.
Classification
Bureau Veritas
Class notations
I HULL MACH AUT-UMS, General cargo Ship, Heavy Cargo (150kN/m2) Complete tanktop, STRENGHT BOTTOM INWATERSURVEY.
Port of Registry
Alkmaar
Flag
Dutch
DWAT
3.833
DWCC Summer
3.730
Length over all
89,43
Breadth over all
13,20
Draft summer
5,25
Air draft in ballast
25,25
Distance WL-HC in ballast
6,05
GT
2.782
NT
1.438
Cargo capacities
Total cubic feet capacity
195569 ft3 grain/bale
Holds/hatches
1 Hold / 1 Hatch, type is fully open hatch, fully boxed and double skinned. Vessel is equipped with pontoon hatchcovers.
Hold #1
Dimensions
60,90 x 10,80 x 8.48
Luiken
60,90 x 10,80 x 8.48
Electrical ventilaton
The vessel is equipped with ventilation system in hold.
Tween decks
Vessel is equipped with Tweendecks.
Tank capacities
Fuel oil specification
MGO DMA 0,1% ISO 8217:2010 DMA. Within: ECA Area t/c operation to be responsible for sulphur limit compliance.
Engines
Main engine
3 x Electro ADDA SPA W400L/6 749kW
